TP304N Stainless Steel Pipes & Tubes


Material Description

UNS S30451

Chemical Composition, %


C

Mn

P

S

Si

Cr

Ni

.08

2.0

.045

.03

1.0

18.0-20.0

8.0-11.0


TP304N is an austenitic stainless steel alloyed with nitrogen. Remarkably higher strength at room to high temperatures and higher fatigue strength than that of TP304.


Corrosion Resistance

Corrosion resistance, heat resistance and physical properties similar to those of TP304


Application

Heat exchanger tubing, condenser tubing, pipelines, cooling and heating coils in the chemical, petrochemical, fertiliser, pulp and paper and nuclear power industries, as well as in the production of pharmaceuticals, foods and beverages.


Seamless Tube Information

Specification: ASTM A-213 / ASME SA-213, ASTM A312 / ASME SA312

Outside Diameter: 6.0-406 mm (1/4’’ – 16’’)

Wall Thickness: 0.5-35 mm (0.0196’’ – 1.378’’)

Length: Max.33000 mm (the maximum length is for the scope of special diameters and walls)

Other sizes are on the request
