Home > Stainless Steel Pipes & TubesTP317L Stainless Steel Pipes & Tubes
Material Description
UNS S31703
Chemical Composition, %
C
Mn
P
S
Si
Cr
Ni
Mo
.035
2.0
.045
.03
1.0
18.0-20.0
11.0-15.0
3.0-4.0
TP317L is an austenitic stainless steel with a high molybdenum content.
The grade is characterized by improved resistance to general and
pitting corrosion in comparison with TP 316L
Corrosion Resistance
● Owing to its high molybdenum content, TP317L possesses improved
resistance compared to TP316/316L in a majority of chloride and acidic
environments.
● Organic acids at high concentrations and moderate temperatures.
● Inorganic acids, e.g. phosphoric and sulphuric acids at moderate
concentrations and temperatures. The steel can also be used in sulphuric
acid of concentrations above 90% at low temperatur.
● Salt solutions, e.g. sulphates, sulphides and sulphites caustic environments.
Application
Heat exchangers, condensers, pipelines, cooling and heating coils in the chemical, petrochemical, pulp and paper and food industries.
Seamless Tube Information
Specification: ASTM A-213 / ASME SA-213, ASTM A312 / ASME SA312
Outside Diameter: 6.0-406 mm (1/4’’ – 16’’)
Wall Thickness: 0.5-35 mm (0.0196’’ – 1.378’’)
Length: Max.33000 mm (the maximum length is for the scope of special diameters and walls)
Other sizes are on the request
